全向型2.4/5.8G區域網路設備雙頻天線

產品

編號

簡述

PDF

下載
TH-2458

Frequency : 2.4~2.5/5.1~5.9GHz
Polarization : Linear
V.S.W.R. : 1 : 1.5 Max
Impedance : 50 OHMS ±5Ω
TH-2458-8

1. ANTENNA TYPE : Base Antenna
2. FREQUENCY : 2.4~2.85/5.15~5.85GHz
3. IMPEDANCE : 50 Ohm
4. POLARISATION : Verticle
TH-2458A

Frequency : 2.4~2.5/5.1~5.9GHz
Polarization : Linear
V.S.W.R. : 1 : 1.5 Max
Impedance : 50 OHMS ±5Ω
TH-2458B

Please click PDF file to detail infromation
TH-2458C

Frequency Band 2.4~2.5 & 5.1~5.85GHz
Nominal Impedance 50 ohm
Polarization Vertical
TH2485-3

1. ANTENNA TYPE : AP Antenna
2. FREQUENCY : 2.4~2.85/5.15~5.85GHz
3. IMPEDANCE : 50 Ohm
